Gigabit AX3000 Wifi6 Router
Model: HC-ZW3000
• 1 10 /100M /1000M Ethernet (WAN) interface
• 3 10 /100M /1000M adaptive Ethernet (LAN) interface, and supports automatic MDI / MDIX
• Support automatic adjustment of wireless transmission rate
• Support 2.4G and 5G Dual frequency band
• 64/128 support B i t WEP Encryption, WPA -PSK, WPA2-PSK, WPA/WPA2-PSK, WPA3-SAE, WPA2-PSK/ WPA3-SAE encryption and security mechanisms can ensure the security of data transmitted in wireless networks
• Four external non- removable high- gain antennas
• SSID support Broadcast control, effectively prevent SSID broadcast leak
• Built-in Network Address Translation (NAT) capability
• Built-in DHCP server
• WEB Software upgrade, free to use the latest software of the router
• Web- enabled management, easy installation wizard
• Support WMM to make your voice and video smoother
• Support VPN Penetrate
• Support UPnP
• Support relay function
• DMZ support
HC-ZW300 is a wireless dual-band Wi-Fi6 router with a transmission rate of 3000Mbps. It adopts MT7981BA +MT7976CN+MT7531AE chipset, dual-core CPU with a main frequency of 1.3GHZ, supports the latest 802.11 ax Wi-Fi technology, and provides a speed of up to 574+2402Mbps. 2 times that of ordinary Wi-Fi5, simultaneous dual-band technology to avoid interference, providing users with faster downloads, smoother video and online gaming experience, and compatible with 802.11b/g/a/n/ac/ax mixing equipment. It also adopts MIMO wireless signal multi-channel technology, four channels of wireless transmission and reception at the same time, and also supports Easy-Mesh networking, which can meet the wireless coverage of multi-room, duplex and other large apartments, small multi-offices, etc. Enjoy wireless networking experience in the corner, compatible with all mainstream smart phones, tablets, PCs and other digital products, making networking smoother and more stable.
Hardware Feature
Processor | MT79781B Dual Core CPU, 1.3GHz main frequency |
WIFI chipset | MT7976CN+MT7531AE, IEEE 802.11n/g/b/a/ac/ax, max speed up to 3000Mbps |
Flash/RAM | 128MB/256MB |
Protocol standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11a, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
WAN/LAN | 1* 10 /100M / 1000M WAN port, supports Auto MDI/MDIX 3* 10/100M / 1000M LAN mouth, support Auto MDI/MDIX |
Button | MESH (press for 1 second) Reset (press and hold for 5 seconds) |
LED | Three-color LED: green, red, blue |
Antennas | 4* External omni directional 5dBi gain non-removable antenna |
Wireless Feature
Wireless enable / disable SSID broadcast enable / disable Channel selection: 1 ~ 13 (2.4G) 36 ~ 48 + 149 ~ 165 (5GHz) 2.4G bandwidth: 20MHz ,40MHz 5G bandwidth: 20MHz ,40MHz ,80MHz | |
2.4G Frequency | 2412 ~ 2472MHz |
5.8G Frequency | 5180~ 5240MHz 5745MHz ~5825MHz |
Wireless Rate | 2.4G 2TR up to 574Mbps 5G 2T2R up to 1201Mbps |
2.4G Wifi Power | 2.4G actual power: 802.11b 2 2 ±1.5dBm 802.11g 21±1.5dBm 802.11n20 19±1.5dBm 802.11n40 19±1.5dBm 802.11ac40 17.5±1.5dBm 802.11ax40 17.5±1.5dBm |
5.8G Wifi power | 802.11a 19±1.5dBm 802.11n20 18.5±1.5dBm 802.11n40 18.5±1.5dBm 802.11ac80 17.5±1.5dBm 802.11ax80 16.5±1.5dBm |
Operation Mode | AP Router Repeater |
Antennas | 4* External omni directional 5dBi gain non-removable antenna |
Wireless Security | Wireless MAC address filtering 64/128bit WEP encryption WPA-PSK, WPA2-PSK, WPA3-SAE, WPA/WPA2-PSK, WPA2-PSK/WPA3-SAE |
Other Feature | Wireless host status display Seamless roaming between nodes Seamless roaming between frequency bands |
Wifi Setting | Wi-Fi basic settings (dual frequency integration, switch, wireless mode, SSID, PWD, encryption algorithm, channel, bandwidth, power adjustment) Advanced Settings (Wireless Client Isolation, 802.11h, WMM Multimedia Acceleration) Multi- SSID (SSID, encryption method, PWD, encryption algorithm) |
Mesh Properties | Mesh switch, Role selection, Networking mode, Mesh-top |
Software Feature
Network Setting | Support WAN port connection type: PPPOE, dynamic IP, static IP MAC address clone, IPV6 settings, Radvd settings, IPTV settings, IGMP settings |
LAN Setting | DHCP server settings Manage IP settings |
Virtual Server | Firewall Settings, Port Forwarding, UPnP, DMZ |
Advanced Settings | Traffic statistics, D DNS settings, QoS settings, VPN settings, anti- rubbing network |
System Management | System status, E -OS setting, time setting, password management, configuration management, firmware upgrade, scheduled restart, system log |
System Tools | Traffic Statistics System log time zone setting Local WEB management control configuration File import and export Web software upgrade |
Work Environment | Operating temperature：0 ℃ to 40 ℃ Storage temperature: -40 ℃ to 70 ℃ Working humidity: 10% to 90%RH non-condensing Storage humidity: 5% to 90%RH condensation |
